Beschreibung
Technische Parameter
Material:Kohlenstoffstahl -40 Cr
| Größe | d0 mm |
Hnom mm |
tfix mm |
SW mm |
| M6X45 | 6 | 31 | 5 | 10 |
| M6X50 | 6 | 31 | 10 | 10 |
| M6X55 | 6 | 41 | 5 | 10 |
| M6X60 | 6 | 41 | 10 | 10 |
| M6X65 | 6 | 41 | 15 | 10 |
| M6X70 | 6 | 41 | 20 | 10 |
| M6X80 | 6 | 41 | 30 | 10 |
| M6X90 | 6 | 41 | 40 | 10 |
| M8X50 | 8 | 33 | 5 | 13 |
| M8X60 | 8 | 33 | 15 | 13 |
| M8X65 | 8 | 48 | 5 | 13 |
| M8X80 | 8 | 48 | 20 | 13 |
| M8X90 | 8 | 48 | 30 | 13 |
| M8X100 | 8 | 48 | 40 | 13 |
| M8X120 | 8 | 48 | 60 | 13 |
| M8X140 | 8 | 48 | 80 | 13 |
| M8X160 | 8 | 48 | 100 | 13 |
| M10X60 | 10 | 44 | 5 | 17 |
| M10X70 | 10 | 44 | 15 | 17 |
| M10X75 | 10 | 59 | 5 | 17 |
| M10X80 | 10 | 59 | 10 | 17 |
| M10X90 | 10 | 59 | 20 | 17 |
| M10X100 | 10 | 59 | 30 | 17 |
| M10X120 | 10 | 59 | 50 | 17 |
| M10X140 | 10 | 59 | 70 | 17 |
| M10X160 | 10 | 59 | 90 | 17 |
| M10X180 | 10 | 59 | 110 | 17 |
| M10X200 | 10 | 59 | 130 | 17 |
| M10X220 | 10 | 59 | 150 | 17 |
| M12X75 | 12 | 51 | 5 | 19 |
| M12X80 | 12 | 51 | 10 | 19 |
| M12X90 | 12 | 51 | 20 | 19 |
| M12X100 | 12 | 71 | 10 | 19 |
| M12X120 | 12 | 71 | 30 | 19 |
| M12X140 | 12 | 71 | 50 | 19 |
| M12X150 | 12 | 71 | 60 | 19 |
| M12X160 | 12 | 71 | 70 | 19 |
| M12X180 | 12 | 71 | 90 | 19 |
| M12X200 | 12 | 71 | 110 | 19 |
| M12X220 | 12 | 71 | 130 | 19 |
| M16X80 | 16 | 56 | 5 | 24 |
| M16X100 | 16 | 56 | 25 | 24 |
| M16X120 | 16 | 56 | 45 | 24 |
| M16X125 | 16 | 96 | 10 | 24 |
| M16X140 | 16 | 96 | 25 | 24 |
| M16X180 | 16 | 96 | 65 | 24 |
| M16X200 | 16 | 96 | 85 | 24 |
| M16X220 | 16 | 96 | 105 | 24 |
| M20X100 | 20 | 75 | 5 | 30 |
| M20X125 | 20 | 75 | 30 | 30 |
| M20X140 | 20 | 115 | 5 | 30 |
| M20X160 | 20 | 115 | 25 | 30 |
| M20X180 | 20 | 115 | 45 | 30 |
| M20X200 | 20 | 115 | 65 | 30 |
| M20X220 | 20 | 115 | 85 | 30 |
| 1/4X1-3/4 | 1/4" | 1-1/4" | 1/8" | 7/16" |
| 1/4X2 | 1/4" | 1-1/4" | 3/8" | 7/16" |
| 1/4X2-1/4 | 1/4" | 1-5/8" | 1/4" | 7/16" |
| 1/4X2-1/2 | 1/4" | 1-5/8" | 1/2" | 7/16" |
| 1/4X2-3/4 | 1/4" | 1-5/8" | 3/4" | 7/16" |
| 1/4X3 | 1/4" | 1-5/8" | 1" | 7/16" |
| 1/4X3-1/4 | 1/4" | 1-5/8" | 1-1/4" | 7/16" |
| 1/4X3-3/4 | 1/4" | 1-5/8" | 1-3/4" | 7/16" |
| 1/4X4-1/2 | 1/4" | 1-5/8" | 2-1/2" | 7/16" |
| 1/4X5 | 1/4" | 1-5/8" | 3" | 7/16" |
| 3/8X2-1/4 | 3/8" | 1-5/8" | 1/8" | 9/16" |
| 3/8X2-3/4 | 3/8" | 1-5/8" | 5/8" | 9/16" |
| 3/8X3 | 3/8" | 2-3/8" | 1/8" | 9/16" |
| 3/8X3-1/2 | 3/8" | 2-3/8" | 5/8" | 9/16" |
| 3/8X3-3/4 | 3/8" | 2-3/8" | 1-1/8" | 9/16" |
| 3/8X4 | 3/8" | 2-3/8" | 1-3/8" | 9/16" |
| 3/8X4-1/2 | 3/8" | 2-3/8" | 1-7/8" | 9/16" |
| 3/8X5 | 3/8" | 2-3/8" | 2-3/8" | 9/16" |
| 3/8X6 | 3/8" | 2-3/8" | 3-3/8" | 9/16" |
| 3/8X6-1/2 | 3/8" | 2-3/8" | 3-7/8" | 9/16" |
| 3/8X7 | 3/8" | 2-3/8" | 4-3/8" | 9/16" |
| 1/2X2-3/4 | 1/2" | 2" | 1/8" | 3/4" |
| 1/2X3 | 1/2" | 2" | 3/8" | 3/4" |
| 1/2X3-1/4 | 1/2" | 2" | 5/8" | 3/4" |
| 1/2X3-1/2 | 1/2" | 2" | 7/8" | 3/4" |
| 1/2X3-3/4 | 1/2" | 2" | 1-1/8" | 3/4" |
| 1/2X4 | 1/2" | 3" | 3/8" | 3/4" |
| 1/2X4-1/4 | 1/2" | 3" | 5/8" | 3/4" |
| 1/2X4-1/2 | 1/2" | 3" | 7/8" | 3/4" |
| 1/2X4-3/4 | 1/2" | 3" | 1-1/8" | 3/4" |
| 1/2X5 | 1/2" | 3" | 1-3/8" | 3/4" |
| 1/2X5-1/2 | 1/2" | 3" | 1-7/8" | 3/4" |
| 1/2X6 | 1/2" | 3" | 2-3/8" | 3/4" |
| 1/2X7 | 1/2" | 3" | 3-3/8" | 3/4" |
| 1/2X8-1/2 | 1/2" | 3" | 4-7/8" | 3/4" |
| 5/8X3-1/2 | 5/8" | 2-9/16" | 3/16" | 15/16" |
| 5/8X4 | 5/8" | 2-9/16" | 11/16" | 15/16" |
| 5/8X4-1/4 | 5/8" | 2-9/16" | 15/16" | 15/16" |
| 5/8X4-1/2 | 5/8" | 2-9/16" | 1-3/16" | 15/16" |
| 5/8X5 | 5/8" | 4-1/16" | 3/16" | 15/16" |
| 5/8X5-1/2 | 5/8" | 4-1/16" | 11/16" | 15/16" |
| 5/8X6 | 5/8" | 4-1/16" | 1-3/16" | 15/16" |
| 5/8X7 | 5/8" | 4-1/16" | 2-3/16" | 15/16" |
| 5/8X8 | 5/8" | 4-1/16" | 3-3/16" | 15/16" |
| 5/8X8-1/2 | 5/8" | 4-1/16" | 3-11/16" | 15/16" |
| 3/4X4-1/4 | 3/4" | 3" | 3/8" | 1-1/8" |
| 3/4X4-3/4 | 3/4" | 3" | 7/8" | 1-1/8" |
| 3/4X5-1/2 | 3/4" | 3" | 1-5/8" | 1-1/8" |
| 3/4X6 | 3/4" | 4-5/8" | 1/2" | 1-1/8" |
| 3/4X6-1/4 | 3/4" | 4-5/8" | 3/4" | 1-1/8" |
| 3/4X7 | 3/4" | 4-5/8" | 1-1/2" | 1-1/8" |
| 3/4X8 | 3/4" | 4-5/8" | 2-1/2" | 1-1/8" |
| 3/4X8-1/2 | 3/4" | 4-5/8" | 3" | 1-1/8" |
